| Item | Part Number | Qty | Description | | Item | Part Number | Qty | Description | | Item | Part Number | Qty | Description |
| 1 | 962308 | 1 | SCR 5/16-18X2&1/4 HX ST | | 22 | 169012 | 1 | TUBE HANDLE 206 | | 44 | 163808 | 1 | Grommet - Motor Leads |
| 2 | 980652 | 2 | WASHER LK 5/16 REGPLTD | | 23 | 57111A | 1 | PLUG-HANDLE TUBE | | 45 | 962409 | 1 | SCR 5/16-18X3 FT ST MACH |
| 3 | 162019 | 1 | 2267C CLAMP HANDLE BAR | | 24 | 960180 | 1 | SCR CLAMP DU8 | | 46 | 54214A | 1 | GUARDDRUM PNTD DU-8R |
| 4 | 163907 | 1 | HDLE CROSS DU8 | | 25 | 167308 | 1 | RINGRETAINING-EXTERNAL .500 | | 47 | 55609A | 1 | LABEL-WARNING |
| 5 | 57961A | 1 | SWITCH-CIRCUIT BREAKER | | 26 | 980673 | 1 | WASHER FLT 1/2 ID X 7/8 OD | | 48 | 165103 | 1 | KIT, LIFTING INSTRUCTIONS |
| 47337A | | SWITCHCIRCUIT BREAKER DU8-R | | 27 | 962244 | 5 | BOLT 3/8-16 X HHCS | | 49 | 962170 | 1 | SCR 10-24X 1/4 ST ST CUPPT |
| 6 | 52723A | 1 | COVER-SWITCH | | 28 | 160815 | 1 | 201 1 BRACKET HANDLE | | 50 | 467308 | 4 | RING IDLR GEAR STUD 189 |
| 7 | | 4 | Screw - #6-32 x 1/4 Type AB | | 29 | 169010 | 1 | TUBE EXHAUST DU8R | | 51 | 962103 | 1 | SCREW 5/16-18 X 3/8 SET KNURL |
| 8 | | 2 | Nut - M10 Hex | | 30 | 60722A | 1 | BAG-DUST-DU8R | | 52 | 167708 | 1 | SHAFT FLOOR ROLLER 35 |
| 9 | 920995 | 1 | NUTHEX JAMPLAINM20-1.5 | | 31 | 160809 | 1 | BRACKET EXHAUST (DU8-R) | | 53 | 160504 | 1 | ADJUSTER FLOOR ROLLER 36 |
| 10 | | 1 | Washer - 3/8 Int Lock | | 32 | 163403 | 1 | GASKET EXHAUST BRKT 31 | | 54 | 980646 | 2 | WASHER 1/4 SAE FLAT PLTD |
| 11 | 160810 | 1 | BRACKET-HANDLE CROSS 960183 | | 33 | 912073 | 1 | BODY TWIST LOCK | | 55 | 962139 | 2 | SCREW 1/4-20 X 5/8 HEX HD |
| 12 | 54314A | 1 | GASKET-SWITCH COVER | | 34 | 85303A | 4 | SCREW 8-32 X 3/8 PN ST PH | | 56 | 163614 | 1 | GUARD-BELT |
| 13 | 167505 | 1 | STRAIN RELIEF DU8R | | 35 | 912072 | 1 | BASE TWIST LOCK | | 57 | 960146 | 4 | SCREW SET OF 4 962405 |
| 14 | 163906 | 1 | 96 HANDLE SINGLE GRIP | | 36 | 962109 | 7 | SCR 10-24X 5/8 PN SS | | 58 | 167404 | 1 | ROD DRUM GUARD 10 |
| 15 | | 1 | Bolt - M10 x 150 Carriage | | 37 | 163615 | 1 | GUARD-WALL END | | 59 | 920256 | 1 | NUT-5/16-18 HEX |
| 16 | 51950A | 1 | CABLE-SUPPLY | | 38 | | 3 | Screw - #8-32 x 7/8 Ft Hd | | 60 | 980629 | 1 | WASHERPLAIN5/16 NOM |
| 17 | 980615 | 2 | WASH 7/16 | | 39 | | 4 | Screw - 10-24 x 5/8 Ft Hd | | 61 | 169504 | 1 | Weight - Balance |
| 18 | 164508 | 1 | HOOK CORD 211 | | 40 | 167804 | 1 | SHIELD WALL END 3 | | 62 | 52719A | 1 | COVER-INLET (DU8R) |
| 19 | 163804 | 1 | 25 GROMMET HANDLE CORD | | 41 | 902567 | 2 | BEARING BALLDOUBLE SEALED | | 63 | 167902 | 1 | SHOE DUST DU-8R |
| 20 | 920342 | 1 | NUT LK 3/8-16 REG | | 42 | 169704 | 2 | ROLLER FLOOR DU8 EACH | | 64 | 962445 | 3 | SCR 10-24X 1/2 RD ST SEMS |
| 21 | 51951A | 1 | CLAMP ASM-LID SS27,SS59 | | 43 | 163201 | 1 | Frame - Main | | | | | |
